Remote Access Services

Dit is die algemene macOS-dienste om op afstand toegang daartoe te verkry.
Jy kan hierdie dienste in System Settings –> Sharing aktiveer/deaktiveer

  • VNC, bekend as “Screen Sharing” (tcp:5900)
  • SSH, genaamd “Remote Login” (tcp:22)
  • Apple Remote Desktop (ARD), of “Remote Management” (tcp:3283, tcp:5900)
  • AppleEvent, bekend as “Remote Apple Event” (tcp:3031)

Kontroleer of enigeen geaktiveer is deur die volgende uit te voer:

rmMgmt=$(netstat -na | grep LISTEN | grep tcp46 | grep "*.3283" | wc -l);
scrShrng=$(netstat -na | grep LISTEN | egrep 'tcp4|tcp6' | grep "*.5900" | wc -l);
flShrng=$(netstat -na | grep LISTEN | egrep 'tcp4|tcp6' | egrep "\\*.88|\\*.445|\\*.548" | wc -l);
rLgn=$(netstat -na | grep LISTEN | egrep 'tcp4|tcp6' | grep "*.22" | wc -l);
rAE=$(netstat -na | grep LISTEN | egrep 'tcp4|tcp6' | grep "*.3031" | wc -l);
bmM=$(netstat -na | grep LISTEN | egrep 'tcp4|tcp6' | grep "*.4488" | wc -l);
printf "\nThe following services are OFF if '0', or ON otherwise:\nScreen Sharing: %s\nFile Sharing: %s\nRemote Login: %s\nRemote Mgmt: %s\nRemote Apple Events: %s\nBack to My Mac: %s\n\n" "$scrShrng" "$flShrng" "$rLgn" "$rmMgmt" "$rAE" "$bmM";

Lys van deelkonfigurasie plaaslik

Wanneer jy reeds lokale code execution op ’n Mac het, kontroleer die gekonfigureerde toestand, nie net die luisterende sockets nie. systemsetup en launchctl sê gewoonlik vir jou of die diens administratief geaktiveer is, terwyl kickstart en system_profiler help om die effektiewe ARD/Sharing-konfigurasie te bevestig:

system_profiler SPSharingDataType
sudo /usr/sbin/systemsetup -getremotelogin
sudo /usr/sbin/systemsetup -getremoteappleevents
sudo /System/Library/CoreServices/RemoteManagement/ARDAgent.app/Contents/Resources/kickstart -status
sudo launchctl print-disabled system | egrep 'com.apple.screensharing|com.apple.AEServer|ssh'

Pentesting ARD

Apple Remote Desktop (ARD) is an enhanced version of Virtual Network Computing (VNC) tailored for macOS, offering additional features. A notable vulnerability in ARD is its authentication method for the control screen password, which only uses the first 8 characters of the password, making it prone to brute force attacks with tools like Hydra or GoRedShell, as there are no default rate limits.

Vulnerable instances can be identified using nmap’s vnc-info script. Services supporting VNC Authentication (2) are especially susceptible to brute force attacks due to the 8-character password truncation.

To enable ARD for various administrative tasks like privilege escalation, GUI access, or user monitoring, use the following command:

sudo /System/Library/CoreServices/RemoteManagement/ARDAgent.app/Contents/Resources/kickstart -activate -configure -allowAccessFor -allUsers -privs -all -clientopts -setmenuextra -menuextra yes

ARD bied veelsydige beheer-vlakke, insluitend observasie, gedeelde beheer, en volle beheer, met sessies wat voortduur selfs nadat gebruikerwagwoordveranderings plaasvind. Dit laat toe om Unix commands direk te stuur, en dit uit te voer as root vir administratiewe gebruikers. Taakskedulering en Remote Spotlight search is noemenswaardige kenmerke, wat afstandlike, lae-impak soektogte vir sensitiewe lêers oor verskeie masjiene fasiliteer.

Van ’n operator-perspektief het Monterey 12.1+ remote-enablement workflows in managed fleets verander. As jy reeds beheer oor die slagoffer se MDM het, is Apple se EnableRemoteDesktop command dikwels die skoonste manier om remote desktop-funksionaliteit op nuwer stelsels te aktiveer. As jy reeds ’n foothold op die host het, is kickstart steeds nuttig om ARD privileges vanaf die command line te inspekteer of te herkonfigureer.

Pentesting Remote Apple Events (RAE / EPPC)

Apple noem hierdie funksie Remote Application Scripting in moderne System Settings. Onder die oppervlak stel dit die Apple Event Manager afstandlik bloot oor EPPC op TCP/3031 via die com.apple.AEServer service. Palo Alto Unit 42 het dit weer uitgelig as ’n praktiese macOS lateral movement primitief omdat geldige credentials plus ’n geaktiveerde RAE service ’n operator toelaat om scriptable applications op ’n remote Mac te beheer.

Nuttige checks:

sudo /usr/sbin/systemsetup -getremoteappleevents
sudo launchctl print-disabled system | grep AEServer
lsof -nP -iTCP:3031 -sTCP:LISTEN

As jy reeds admin/root op die teiken het en dit wil aktiveer:

sudo /usr/sbin/systemsetup -setremoteappleevents on

Basiese konnektiwiteitstoets vanaf ’n ander Mac:

osascript -e 'tell application "Finder" of machine "eppc://user:pass@192.0.2.10" to get name of startup disk'

In praktyk is die abuse case nie beperk tot Finder nie. Enige scriptable application wat die vereiste Apple events aanvaar, word ’n remote attack surface, wat RAE veral interessant maak ná credential theft op interne macOS-netwerke.

Recent Screen-Sharing / ARD vulnerabilities (2023-2025)

YearCVEComponentImpactFixed in
2023CVE-2023-42940Screen SharingIncorrect session rendering could cause the wrong desktop or window to be transmitted, resulting in leakage of sensitive informationmacOS Sonoma 14.2.1 (Dec 2023)
2024CVE-2024-44248Screen Sharing ServerA user with screen sharing access may be able to view another user’s screen because of a state-management issuemacOS Ventura 13.7.2 / Sonoma 14.7.2 / Sequoia 15.1 (Oct-Dec 2024)

Hardening tips

  • Disable Screen Sharing/Remote Management when not strictly required.
  • Keep macOS fully patched (Apple generally ships security fixes for the last three major releases).
  • Use a Strong Password and enforce the “VNC viewers may control screen with password” option disabled when possible.
  • Put the service behind a VPN instead of exposing TCP 5900/3283 to the Internet.
  • Add an Application Firewall rule to limit ARDAgent to the local subnet:
sudo /usr/libexec/ApplicationFirewall/socketfilterfw --add /System/Library/CoreServices/RemoteManagement/ARDAgent.app/Contents/MacOS/ARDAgent
sudo /usr/libexec/ApplicationFirewall/socketfilterfw --setblockapp /System/Library/CoreServices/RemoteManagement/ARDAgent.app/Contents/MacOS/ARDAgent on

Bonjour Protocol

Bonjour, an Apple-designed technology, allows devices on the same network to detect each other’s offered services. Known also as Rendezvous, Zero Configuration, or Zeroconf, it enables a device to join a TCP/IP network, automatically choose an IP address, and broadcast its services to other network devices.

Zero Configuration Networking, provided by Bonjour, ensures that devices can:

  • Automatically obtain an IP Address even in the absence of a DHCP server.
  • Perform name-to-address translation without requiring a DNS server.
  • Discover services available on the network.

Devices using Bonjour will assign themselves an IP address from the 169.254/16 range and verify its uniqueness on the network. Macs maintain a routing table entry for this subnet, verifiable via netstat -rn | grep 169.

For DNS, Bonjour utilizes the Multicast DNS (mDNS) protocol. mDNS operates over port 5353/UDP, employing standard DNS queries but targeting the multicast address 224.0.0.251. This approach ensures that all listening devices on the network can receive and respond to the queries, facilitating the update of their records.

Upon joining the network, each device self-selects a name, typically ending in .local, which may be derived from the hostname or randomly generated.

Service discovery within the network is facilitated by DNS Service Discovery (DNS-SD). Leveraging the format of DNS SRV records, DNS-SD uses DNS PTR records to enable the listing of multiple services. A client seeking a specific service will request a PTR record for <Service>.<Domain>, receiving in return a list of PTR records formatted as <Instance>.<Service>.<Domain> if the service is available from multiple hosts.

The dns-sd utility can be employed for discovering and advertising network services. Here are some examples of its usage:

Searching for SSH Services

To search for SSH services on the network, the following command is used:

dns-sd -B _ssh._tcp

Hierdie opdrag begin deur _ssh._tcp-dienste te blaai en gee besonderhede uit soos tydstempel, vlae, koppelvlak, domein, diens tipe, en instansienaam.

Adverteer van ’n HTTP-diens

Om ’n HTTP-diens te adverteer, kan jy gebruik:

dns-sd -R "Index" _http._tcp . 80 path=/index.html

Hierdie opdrag registreer ’n HTTP-diens genaamd “Index” op poort 80 met ’n pad van /index.html.

Om dan na HTTP-dienste op die netwerk te soek:

dns-sd -B _http._tcp

Wanneer ’n diens begin, kondig dit sy beskikbaarheid aan alle toestelle op die subnet aan deur sy teenwoordigheid te multicast. Toestelle wat in hierdie dienste belangstel, hoef nie versoeke te stuur nie, maar luister eenvoudig vir hierdie aankondigings.

Vir ’n meer gebruikersvriendelike koppelvlak kan die Discovery - DNS-SD Browser-app wat op die Apple App Store beskikbaar is, die dienste wat op jou plaaslike netwerk aangebied word, visualiseer.

Alternatiewelik kan pasgemaakte scripts geskryf word om dienste te browse en te ontdek met behulp van die python-zeroconf-biblioteek. Die python-zeroconf script demonstreer hoe om ’n diens-blaaier vir _http._tcp.local.-dienste te skep, en druk bygevoegde of verwyderde dienste:

from zeroconf import ServiceBrowser, Zeroconf

class MyListener:

def remove_service(self, zeroconf, type, name):
print("Service %s removed" % (name,))

def add_service(self, zeroconf, type, name):
info = zeroconf.get_service_info(type, name)
print("Service %s added, service info: %s" % (name, info))

zeroconf = Zeroconf()
listener = MyListener()
browser = ServiceBrowser(zeroconf, "_http._tcp.local.", listener)
try:
input("Press enter to exit...\n\n")
finally:
zeroconf.close()

macOS-spesifieke Bonjour-jag

Op macOS-netwerke is Bonjour dikwels die maklikste manier om veraf-administrasie-oppervlaktes te vind sonder om die teiken direk aan te raak. Apple Remote Desktop self kan kliënte deur Bonjour ontdek, so dieselfde ontdekkingsdata is nuttig vir ’n aanvaller.

# Enumerate every advertised service type first
dns-sd -B _services._dns-sd._udp local

# Then look for common macOS admin surfaces
dns-sd -B _rfb._tcp local      # Screen Sharing / VNC
dns-sd -B _ssh._tcp local      # Remote Login
dns-sd -B _eppc._tcp local     # Remote Apple Events / EPPC

# Resolve a specific instance to hostname, port and TXT data
dns-sd -L "<Instance>" _rfb._tcp local
dns-sd -L "<Instance>" _eppc._tcp local

Vir breër mDNS spoofing, impersonation, and cross-subnet discovery tegnieke, kyk na die toegewyde bladsy:

5353/UDP Multicast DNS (mDNS) and DNS-SD

Enumerating Bonjour oor die netwerk

  • Nmap NSE – ontdek services wat deur ’n enkele host geadverteer word:
nmap -sU -p 5353 --script=dns-service-discovery <target>

Die dns-service-discovery script stuur ’n _services._dns-sd._udp.local query en enumereer dan elke geadverteerde service type.

  • mdns_recon – Python tool wat hele ranges skandeer op soek na misconfigured mDNS responders wat unicast queries antwoord (nuttig om devices te vind wat oor subnets/WAN bereikbaar is):
git clone https://github.com/chadillac/mdns_recon && cd mdns_recon
python3 mdns_recon.py -r 192.0.2.0/24 -s _ssh._tcp.local

Dit sal hosts teruggee wat SSH via Bonjour buite die local link blootstel.

Security considerations & recent vulnerabilities (2024-2025)

JaarCVESeverityIssueGepatch in
2024CVE-2024-44183MediumA logic error in mDNSResponder allowed a crafted packet to trigger a denial-of-servicemacOS Ventura 13.7 / Sonoma 14.7 / Sequoia 15.0 (Sep 2024)
2025CVE-2025-31222HighA correctness issue in mDNSResponder could be abused for local privilege escalationmacOS Ventura 13.7.6 / Sonoma 14.7.6 / Sequoia 15.5 (May 2025)

Mitigation guidance

  1. Beperk UDP 5353 tot link-local scope – blokkeer of rate-limit dit op wireless controllers, routers, en host-based firewalls.
  2. Deaktiveer Bonjour heeltemal op systems wat nie service discovery benodig nie:
sudo launchctl unload -w /System/Library/LaunchDaemons/com.apple.mDNSResponder.plist
  1. Vir environments waar Bonjour intern vereis word maar nooit netwerkgrense mag kruis nie, gebruik AirPlay Receiver profile restrictions (MDM) of ’n mDNS proxy.
  2. Aktiveer System Integrity Protection (SIP) en hou macOS op datum – albei vulnerabilities hierbo is vinnig gepatch maar het daarop gesteun dat SIP geaktiveer is vir volle protection.

Disabling Bonjour

As daar concerns is oor security of ander redes om Bonjour te deaktiveer, kan dit met die volgende command afgeskakel word:

sudo launchctl unload -w /System/Library/LaunchDaemons/com.apple.mDNSResponder.plist
